Description

Materials

• Engineering plastics made water inlet and outlet
• Mechanical seal module material: Graphite/Silicon Carbide
• O-ring:NBR
• Aluminium motor casing

Motor

• 230/380V asynchronous two-pole motor
• Protection class: IP55
• Insulation class: F
• Continuous operation capability
• Built-in overheat protection short circuit device

Working Conditions

• Working Temp: 5-50°C
• Ambient Temp≤40°C
• Working pressure:0.3MPa
• Max Self -priming Height: 1.5mete
